X FLAC Encoder - Free FLAC Encoder for Windows

X FLAC Encoder converts WAV, MP3, M4A, OGG, DSD and other audio to lossless FLAC with the official FLAC encoder. It encodes whole albums in parallel, verifies each file, keeps 24-bit audio, and adds ReplayGain, tags and cover art. Free and portable.

Version
1.1
Size
25.5 MB
Windows
10 and 11
Price
Free
X FLAC Encoder
X FLAC Encoder 1.1 - queue with eight 24-bit WAV files, size and estimated FLAC size for each
Advertisement
Portable app
Encode, decode, test - WAV to FLAC, FLAC to WAV, integrity check
Batch with parallel workers - a whole album at once
Verify and 24-bit aware - what goes in comes out
ReplayGain, tags, cover art - written while encoding
Free - Windows 10 and 11 - v1.1 - 25.5 MB

New in 1.1 "Fresh Coat": see what's new → Needs flac.exe next to it - first start.

Advertisement

What X FLAC Encoder does

Encode to FLAC - compression levels 0 to 8 with four presets, from Fast to Maximum. Every level is lossless
Decode FLAC to WAV - bit-perfect WAV from FLAC and OGG-FLAC, with the original sample rate and bit depth
Test FLAC integrity - checks files against the MD5 stored inside them. Nothing is written
Verify after encoding - the new FLAC is decoded and compared with the source while it is written
Batch queue with parallel workers - drop files or folders and encode several files at once, up to 16
24-bit and 32-bit aware - the bit depth of each source is read first, so hi-res masters are not cut down to 16-bit
More than WAV - MP3, AAC, M4A, OGG, Opus, WMA, APE, WavPack, AIFF, DSD and the audio of MP4 and MKV, decoded with FFmpeg
ReplayGain - per track, or for a whole album so the tracks keep their loudness against each other
Tags, cover art, cuesheet - type the tags or copy them from the source files; embed a JPEG or PNG cover and a .cue sheet
Command preview and presets - see the exact flac command for your settings, and save them as a preset file
Dark and light theme, large text - switch with Ctrl+T; both are remembered
Free, no install - one .exe, no ads in the app, nothing is uploaded

X FLAC Encoder screenshots

X FLAC Encoder 1.1 - queue with eight 24-bit WAV files, size and estimated FLAC size for eachX FLAC Encoder 1.1 - encoding an album to FLAC with a progress bar per file and overall progressX FLAC Encoder 1.1 - eight files encoded to FLAC, all marked doneX FLAC Encoder 1.1 - Encoder tab with operation, preset, compression level, verify, ReplayGain and the flac command previewX FLAC Encoder 1.1 - Advanced tab with exhaustive model search, LPC order, block size, padding and threadsX FLAC Encoder 1.1 - Tags tab with title, artist, album, genre, cover art and cuesheetX FLAC Encoder 1.1 - Output tab with output folder, filename template, existing-file rule and parallel workersX FLAC Encoder 1.1 - Settings tab showing flac.exe, metaflac.exe, ffmpeg.exe and ffprobe.exe found, update check, theme and text sizeX FLAC Encoder 1.1 - light theme

Queue - files, bit depth and estimated FLAC size (1 / 9)

How to convert WAV to FLAC with X FLAC Encoder

First start: the encoder programs

X FLAC Encoder is the window. The official FLAC encoder does the encoding.

  1. Get FLAC. Download FLAC from free-codecs.com and put flac.exe and metaflac.exe in the same folder as X-FLAC-Encoder.exe.
  2. Get FFmpeg for other formats. For MP3, M4A, OGG, DSD and video files, add ffmpeg.exe and ffprobe.exe from FFmpeg on free-codecs.com.
  3. Check the Settings tab. Each program shows "found". Programs on the Windows PATH are found too.

Good to know: the programs stay separate files, so you can replace them with a newer FLAC or FFmpeg at any time.

Convert WAV to FLAC

FLAC makes a WAV file roughly 40 to 60 percent smaller, with no loss.

  1. Add the files. Drop files or a folder on the Queue tab, or use Add files and Add folder.
  2. Pick a preset. On the Encoder tab, Balanced (level 5) is selected and suits most music.
  3. Pick the output folder. On the Output tab, or leave it empty to save next to the source.
  4. Click Start encoding. The button and the overall progress are visible on every tab.

Choose a compression level

Every level from 0 to 8 is lossless. The level only trades time for file size.

  1. Fast (level 3). Quick, files a few percent larger. No verify pass.
  2. Balanced (level 5). The FLAC default, with verify switched on.
  3. Archival (level 8). Smallest files at normal speed, with verify and ReplayGain.
  4. Maximum (-8 -e -p). Much slower for a very small gain. For archives you encode once.

Good to know: the Advanced tab holds block size, LPC order, padding and threads. Leave them at 0 to use the preset.

Add ReplayGain

ReplayGain stores how loud a track is, so a player can level the volume. The audio is not changed.

  1. Tick Calculate ReplayGain on the Encoder tab. Each file gets its own track gain.
  2. Tick Treat as one album when the queue is one album. All tracks share one album gain. This needs metaflac.exe.

Tags, cover art and cuesheets

Everything on the Tags tab is written into the FLAC files.

  1. Copy tags from the source files to keep what MP3 or M4A files already have.
  2. Or type them. Artist, album, year and genre apply to every file in the queue.
  3. Add a cover. Browse for a JPEG or PNG. Add a .cue sheet for a one-file album.

Convert FLAC back to WAV

The WAV you get is bit for bit the audio that went into the FLAC.

  1. Pick Decode FLAC to WAV as the operation on the Encoder tab.
  2. Add the FLAC files and start. The queue, output folder and workers work the same way.

Good to know: for MP3 or AAC output use X Audio Converter or X AAC Encoder.

Test your FLAC files

A FLAC file carries an MD5 of its audio. A test finds files damaged by a bad disk or a bad copy.

  1. Pick Test FLAC integrity on the Encoder tab.
  2. Add a folder and start. Each file is marked passed or error in the queue. Nothing is written.

What's new in X FLAC Encoder

v1.1 "Fresh Coat" November 2026 latest
  • New look: icon tabs, cards, dark and light theme (Ctrl+T) and large text
  • Queue, Encoder, Advanced, Tags and Output are tabs of one window
  • Start button and overall progress visible on every tab
  • Settings tab: shows which encoder programs were found, theme and text size
  • Daily update check; theme and text size are remembered
v1.0 April 2026 2 changes
  • First release: encode to FLAC, decode to WAV and test integrity
  • Batch queue with parallel workers, verify, ReplayGain, tags, cover art and cuesheets

FLAC encoding - frequently asked questions

Is X FLAC Encoder really free?
Yes - free for personal and commercial use. No paid tier, no ads in the app and no bundled software. Like every tool on xcodecpack.com it is funded by the ads on this site.
How do I convert WAV to FLAC on Windows?
Start X FLAC Encoder, drop the WAV files on the Queue tab and click Start encoding. The Balanced preset (level 5, with verify) is selected and suits most music.
Do I need to download flac.exe separately?
Yes. X FLAC Encoder is the window around the official FLAC encoder. Put flac.exe and metaflac.exe next to X-FLAC-Encoder.exe, and ffmpeg.exe and ffprobe.exe if you convert other formats than WAV. The Settings tab shows which ones were found.
Which formats can I convert to FLAC?
WAV directly. With FFmpeg next to the app also MP3, AAC, M4A (including Apple Lossless), OGG, Opus, WMA, APE, WavPack, AIFF, MKA, DSD (DSF and DFF) and the audio track of MP4, MKV, AVI, MOV and WebM files.
Does converting MP3 to FLAC improve the sound?
No. FLAC keeps exactly what it is given, so an MP3 in FLAC sounds like the MP3 and takes more space. FLAC is worth it for lossless sources: WAV, AIFF, CD rips, Apple Lossless, APE, WavPack and DSD.
Does it keep 24-bit and 32-bit audio?
Yes. The bit depth of each source is read first and kept through the whole conversion, so a 24-bit master stays 24-bit. The queue shows the bit depth of every file.
Is level 8 better quality than level 5?
No. Every FLAC level is lossless and decodes to the same audio. A higher level takes longer and makes the file a few percent smaller. Level 5 is the usual choice; level 8 pays off for large archives.
What does Verify after encoding do?
While the FLAC is written it is decoded again and compared with the source. If the two differ, the file is reported as failed instead of being kept as a silent error.
What is ReplayGain and should I use it?
ReplayGain is a tag that says how loud a track is, so the player can level the volume between songs. The audio is not changed. Use it if your player reads the tags - foobar2000, mpv and most modern players do.
Can I convert FLAC back to WAV?
Yes. Pick Decode FLAC to WAV on the Encoder tab. The WAV is bit for bit the audio that was encoded.
How is it different from FLAC Frontend?
FLAC Frontend takes WAV only and encodes one file after another. X FLAC Encoder also takes MP3, M4A, OGG, DSD and video files, encodes several files at once, embeds cover art, does album ReplayGain and has a dark and a light theme.
Is my audio uploaded anywhere?
No. Everything runs on your PC. The only connection the app makes is a small daily check for a new version, which you can switch off on the Settings tab.
Which Windows versions does it run on?
Windows 10 and 11, 64-bit. It is a single portable .exe - no install.

Get X FLAC Encoder for Windows

Free - Windows 10 and 11 - v1.1 - portable .exe - no install

Download X FLAC Encoder 1.1

Needs flac.exe next to it - see First start.
